At the heart of numerous industrial operations, hydraulic cylinders are constantly exposed to extreme pressures, abrasive contamination, and temperature fluctuations, all of which can lead to failure. With performance demands and lifecycle expectations constantly increasing, the integrity of every component is paramount. In this case study, we analyze a catastrophic failure of a hydraulic cylinder in a plastic injection molding machine, comparing the failure conditions of different components within the cylinder to highlight key differences.
System Assessment: Hidden Dangers Behind Abnormal Pressure
When a customer reported a lack of power on a critical hydraulic cylinder in their plastic injection molding machine, our service team immediately responded to the site. The machine had recently had its pump replaced by the manufacturer, initially raising suspicions about the new pump. Upon arrival, the team observed that the seemingly intact cylinder was struggling to operate properly during the hard mechanical lockup of the main press.
Connecting a pressure gauge to the rear end of the cylinder, we recorded a mere 1200 psi during compression, well below the set safety relief pressure of 2750 psi. Initially, we suspected a problem with the pump or the main relief valve, but all other machine functions were reaching normal pressure. This prompted us to perform a bypass test on the cylinder: we removed the mold body, fully extended the cylinder, disconnected the rod-side hose, and placed a 5-gallon bucket under the connection. When the operator activated the cylinder, fluid gushed out in an “umbrella-like” pattern, quickly flooding the bucket—a clear indication of a significant bypass leak.
Based on these findings, the customer decided to remove the cylinder and send it to our facility for further evaluation and repair. It’s worth noting that we had previously repaired this cylinder five years ago and flame-sprayed the rod with a tungsten carbide coating. We chose to do this work in-house due to both time constraints and our technical capabilities.
In-Depth Analysis: Root Cause of Failure and Component Repair
After the cylinder was transported back to the workshop and disassembled, the cause of the bypass leak was finally revealed. We suspected contaminants from the replaced pump caused wear on the cylinder’s internal surface and triggered a series of chain reactions. The details are as follows:
Piston Repair
The piston had become severely chipped due to continued wear. Our team decided to remanufacture the piston to accommodate a different wear pad and seal layout:
- The original opposed U-cup design was replaced with a more sophisticated four-piece seal.
- The new design ensures continuous lubrication of the wear rings.
- This design contrasts sharply with the original design, which placed two wear rings between two opposing U-cups, creating a low-pressure area and limiting lubrication.
- We replaced it with a single seal between two ¾-inch wear rings, ensuring adequate lubrication.
Cylinder Barrel tube Restoration: This cylinder barrel tube had some of the most severe wear we’ve ever seen. The restoration involved using a “sacrificial” sleeve barrel tube: the old sleeve barrel was pressed out, replaced with a new one, and then honed.
Cylinder Head Replacement
The cylinder head showed severe wear in all areas exposed to the cylinder barrel. We arranged for a mechanic to rebuild the head to original factory specifications and reinstall it.
While most components were severely damaged, the tungsten carbide-coated cylinder rod was a standout: while surrounding components were damaged, it remained intact, without a single scratch, and completely withstood the direct impact. Aside from the reused outer barrel containing the sacrificial sleeve, the cylinder rod was the only component to survive.
During the system assessment, we inspected the tank fluid and found numerous reflective particles, resembling the residue of a flashbang explosion. This indicated complete contamination of the fluid. Therefore, we replaced all fluids and filters and thoroughly flushed the system using the filtration system to ensure particle counts met acceptable standards before reinstalling the repaired cylinder. We will continue to investigate the system for other affected valves that may exhibit similar damage characteristics to the cylinder.
Flame Spray Technology Explained
Flame spraying is a high-performance thermal process that deposits a uniform, high-hardness coating on component surfaces. Tungsten carbide flame spray coatings are formed by melting carbide powder in a high-temperature flame and spraying it at high velocity onto the substrate surface. Upon impact with the substrate, the particles flatten and rapidly solidify, forming a dense, metallurgically bonded coating.
This microstructural transformation imparts exceptional wear resistance, excellent thermal stability, and fine crystal alignment to the coating, typically achieving a hardness of 80–90 HRC. Tungsten carbide applied via flame spraying is significantly harder than traditional coatings, and this inherent hardness provides exceptional resistance to corrosive wear and scratching—as demonstrated in this example of a cylinder rod.
The coating’s durability extends the life of critical components, potentially reducing maintenance intervals and overall system downtime. However, it should be noted that producing high-quality flame spray coatings is a specialized field, primarily due to the significant investment in equipment and expertise required to produce them.
Comparison of Standard Coating Options
The following is a comprehensive comparison of flame sprayed tungsten carbide coatings and other surface treatment processes
Conclusion
The insights gained from this case study reveal the destructive effects of long-term contamination on components and demonstrate the benefits of advances in surface engineering technology for protecting hydraulic systems. The stark contrast between the intact cylinder rod and the failed component highlights the potential of integrating such surface treatment technologies to improve system reliability and extend life. While not intended for direct promotion, these findings undoubtedly provide engineers and system designers with an opportunity to rethink material protection strategies and overall system resilience.
This case study is not only one of our most memorable repair experiences but also vividly demonstrates the practicality and durability of tungsten carbide coatings in real-world applications. The coated cylinder rod remained unscathed in the face of a catastrophic failure of seals, wear rings, pistons, barrels, and cylinder heads, a testament to the unparalleled durability and performance of advanced coating technology.
