Among the many key components of hydraulic systems, double-acting single-rod hydraulic cylinders, thanks to their unique structure and operating mode, are widely used in various types of machinery. Their operating conditions primarily include rodless chamber oil flow, rod chamber oil flow, and differential connection. Each offers distinct advantages in force and speed performance, and there are significant differences in machine tool and other application scenarios. Today, let’s discuss a comparison of these three types.
1. Oil Injection into the Rodless Chamber: Powerful and Steady Forward
Principle and Characteristics
When hydraulic oil is injected into the rodless chamber of a double-acting, single-rod hydraulic cylinder, the piston, pushed by the oil pressure, drives the piston rod to extend, thus extending the cylinder. At this point, the effective area of the piston is the entire piston area. According to the force equation, a larger effective area generates greater force at the same pressure. However, according to the flow equation, for a given flow rate, a larger effective area means a relatively lower piston speed.
Application Areas
On machine tools, rodless hydraulic cylinders are primarily used for heavy-duty cutting processes. For example, milling large molds and turning large shaft parts require strong cutting forces to overcome material resistance. When milling large workpieces on gantry milling machines, the worktable feed relies on a double-acting, single-rod hydraulic cylinder with rodless chamber oil feed. This cylinder provides sufficient force to ensure smooth and precise movement of the worktable, ensuring stability and machining accuracy during the cutting process. Machine tools demand extremely high machining precision. While rodless chamber oil feed has a low speed, this slow and stable movement helps maintain the relative position accuracy between the tool and the workpiece, reducing machining errors.
In concrete pump trucks, boom extension is a typical application of rodless chamber oil feed. Boom extension requires strong support and stability. Cylinders with rodless chamber oil feed provide sufficient force to extend the boom to the desired position while ensuring that the boom does not shake during concrete pumping, which could affect pouring quality. Unlike machine tool applications, concrete pump trucks have relatively less stringent speed requirements and focus more on the load-bearing capacity and stability of the cylinder to adapt to different working environments and operational needs.
2. Rod Chamber Oil Supply: Light and Fast Retraction
Principle and Characteristics
When hydraulic oil enters the rod chamber, the piston, under the pressure of the oil, moves toward the bottom of the cylinder barrel, retracting the piston rod and completing the retraction. At this point, the effective area of the piston is the piston area minus the cross-sectional area of the piston rod, which is smaller than when oil is supplied from the rodless chamber. According to the force formula, under the same pressure, the force generated by oil supply from the rod chamber is smaller. However, due to the smaller effective area, the piston movement speed is relatively higher at a constant flow rate.
Applications
The tool changing process in machine tools places specific demands on the speed and accuracy of the hydraulic cylinder. For example, in machining centers, after completing a cutting task, the tool holder is typically retracted using rod chamber oil supply. Although this method generates a smaller force, it is sufficient to meet the requirements for unloaded tool holder retraction. Its high speed significantly reduces tool change time and improves machine tool efficiency. At the same time, machine tools demand high accuracy and repeatability during tool changes. The rod-type hydraulic system ensures rapid retraction while ensuring the toolholder returns to its precise initial position, ready for the next tool change.
On stamping machines used in automotive manufacturing, rod-type hydraulic system is a common application for retracting the die after stamping. The die retraction mechanism of stamping machines utilizes a double-acting, single-rod hydraulic cylinder with rod-type hydraulic system, enabling rapid retraction with minimal force, improving stamping cycle time. Compared to tool changes on machine tools, the retraction speed requirement on stamping machines is even more critical, as it directly impacts overall production efficiency. While there are certain standards for the accuracy of the retraction position, the tolerance range can be slightly wider than the high-precision requirements of machine tool tool changes.
3. Differential Connection: Extremely Fast and Light-Loaded Advance
Principle and Characteristics
A differential connection is a special operating method that connects the rodless and rod chambers via an oil pipe and simultaneously introduces pressurized oil. Because the effective area of the rodless chamber is larger than that of the rod chamber, the piston extends due to the pressure difference between the two sides. At this point, the oil flow entering the rodless chamber comes partly from the pump output and partly from the rod chamber. In other words, the oil discharged from the rod chamber does not return to the tank but instead participates in the piston’s movement, increasing the piston’s speed and achieving the fastest possible movement. This is commonly known as “flow regeneration.” Regarding the applied force, although the rodless chamber has a larger effective area, the pressurized oil flowing into the rod chamber partially offsets the pressure in the rodless chamber, resulting in a smaller force than when the rod chamber is supplied with oil alone, but greater than when the rod chamber is supplied with oil alone.
Application Areas
Differential coupling plays a vital role in the rapid feed phase of machine tools. For example, CNC lathes often employ differential coupling to save time and improve machining efficiency during the tool approach to the workpiece. During this phase, the tool load is light, and the differential coupling allows the worktable to quickly approach the workpiece at a higher speed, reducing idle travel time. When the tool is about to contact the workpiece, it switches to another appropriate operating mode for precise machining. This application leverages the high speed of the differential coupling while meeting the machining accuracy requirements of the machine tool, achieving a perfect combination of efficiency and precision.
In automated sorting equipment in the logistics industry, the item push mechanism sometimes utilizes a double-acting, single-rod hydraulic cylinder with a differential coupling. For example, when sorting light packages on a conveyor belt, it is necessary to quickly push the packages to designated diversion channels. Cylinders with differential couplings can achieve this push action at a higher speed with less force, meeting the speed requirements of logistics sorting. Compared to machine tool applications, logistics sorting equipment has lower precision requirements and places greater emphasis on operating speed and efficiency to accommodate the rapid sorting of large quantities of items.
Brief summary
Each of these three operating modes of a double-acting, single-rod hydraulic cylinder offers unique advantages in force and speed. In machine tools and other applications, these three modes demonstrate varying application and importance, depending on their operating characteristics and requirements. Engineers must carefully consider these differences and optimally select the cylinder’s operating mode to optimize hydraulic system performance and ensure efficient and stable operation of various types of machinery.
